Installations Guide

Before applying interior films, the surface condition of where to be applied must be checked for a proper installation.

MDF

Please use densely homogenous MDFs, this enhances adhesion and fire retardant performance.

Iron plate (aluminium, iron, etc.) steel

Remove contaminants such as oil on the surface with solvents such as alcohol, check for damage to the surface due to solvents, treat irregularities and welding areas with filler and remove any foreign matter with wallpaper scrapers, sandpaper etc. and then clean area with lint free cloths and cleaning brushes.

Ready-made products

Depending on the surface condition, the primer must be used to prevent shrinkage and dropout, and the surface must be checked prior to the installation.

– Before installation, inspection of the product selected by the consumer (product name, pattern, appearance status) must be re-checked in advance.

– Installation work must be conducted after inspection of all preparation works done, this includes the coating, painting and sealant process of any woodwork or porous substrates.

– For a stable working environment, check the humidity of the construction site and keep the room temperature at (15°C to 25°C) if possible.

– The across section – overlapping area (cutting area) of the surfaces (MDF, etc.) where the film will be applied must be sufficiently cleaned or polished with sandpaper. The condition of the wood surface (particularly the edges) is rough, it must be cleaned or polished with sandpaper or applied after filler treatment.

– Apply a sufficient primer to the surface of substrate (MDF, PB, etc.) 1-2 times.

– Since the cutting (slit) surface of wood has a high absorption rate and uneven surfaces, the primer should be fully applied 2-3 times.

– Primers will need approximately 2 hours drying time. It is advised and recommended that you check the substrate and thoroughly dry and clean prior to installation.

Once the primer surface is dry enough, make the surface smooth and overlapping section is needed to be cleaned with sandpaper and remove residue with a lint free cloth and make sure area is completely dust free.

– Surface treatment by using sandpapers is required and make sure the surface is clean before applying primer to enhance adhesion performance.

– Please make a pressure using by Helt or Hera (Spatula). Rubbing or Hard Pressure may work to strengthen the Adhesion 2-3 times.

– Apply interior films carefully, not wrapping films forcefully pull over MDF plates, heat or humidity can cause a MDF distortion.

UG (Paper Textured Wood Product)

– This product features a special coating on the film surface to maximize matte finish. Please use a wool felt tool to avoid damaging the surface treatment when applying strong pressure with a squeeze.

– If exposed to contaminants for a long period, there is a risk of discoloration or color transfer. Please remove any contaminants promptly.

Glossy (XG/XF 7100 ~ XG/XF 7102)

– As the color of this product may vary depending on the angle, please make sure to inspect the product before installation.

Superior Matte (JG)

– This product has a special coating on the film surface, which may crack if excessive tension is applied.

JG 698

– This product utilizes a special method involving aluminum. Be cautious during installation as delamination of the surface layer may occur due to detachment between overlapping film sections.

PREMIUM MATT LINE-UPs, SOFT MATT (Solid)

– As being treated with a special process on the surfaces, it feels initially not sticky enough in the overlapped parts, but being fully pressed adhesive parts will be stabilized stronger over time. (Method when contaminated: Wipe with an alkaline alcohol to remove.)
